Security

Secured by WireGuard®
All control plane and container traffic encrypted end-to-end. No TLS certificates to manage — just keypairs.

Banyan authenticates all gRPC communication between components. Every RPC call carries credentials that the engine validates before processing the request.

Auth methods

Method	Status	How it works
Public Key Whitelist	Default	Each component generates a WireGuard keypair. The engine validates public keys against a whitelist directory.
mTLS	Planned	Mutual TLS with client certificates
OIDC / SSO	Planned	Delegate authentication to an identity provider

---

Public Key Whitelist

This is Banyan’s default authentication method. Each component generates an X25519 keypair during init. The same keypair is used for both authentication (control plane) and WireGuard overlay encryption (data plane).

How it works

There are two distinct phases: init time (one-time setup) and runtime (ongoing operation).

Init-time flow

During init, each component generates a WireGuard keypair. The admin then copies agent/CLI public keys to the engine’s whitelisted keys directory:

sequenceDiagram
    participant Admin
    participant Engine as banyan-engine
    participant Agent as banyan-agent
    participant CLI as banyan-cli

    Note over Admin,Engine: Step 1: Engine init
    Admin->>Engine: banyan-engine init
    Engine->>Engine: Generate X25519 keypair
    Engine->>Engine: Save private key + public key to config
    Engine->>Engine: Create /etc/banyan/whitelisted-keys/

    Note over Admin,Agent: Step 2: Agent init
    Admin->>Agent: banyan-agent init
    Agent->>Agent: Generate X25519 keypair
    Agent->>Agent: Save private key + public key to config
    Agent->>Agent: Display public key

    Note over Admin,Engine: Step 3: Whitelist agent key
    Admin->>Engine: Copy agent public key to engine
    Note right of Admin: echo '<pubkey>' > /etc/banyan/whitelisted-keys/worker-1.pub

    Note over Admin,CLI: Step 4: CLI init
    Admin->>CLI: banyan-cli init
    CLI->>CLI: Generate X25519 keypair
    CLI->>CLI: Save private key + public key to config
    CLI->>CLI: Display public key

    Note over Admin,Engine: Step 5: Whitelist CLI key
    Admin->>Engine: Copy CLI public key to engine
    Note right of Admin: echo '<pubkey>' > /etc/banyan/whitelisted-keys/cli-1.pub

    Note over Admin,Engine: Step 6: Start engine
    Admin->>Engine: sudo systemctl start banyan-engine
    Engine->>Engine: Load all *.pub from whitelisted-keys/
    Engine->>Engine: Start gRPC server with pubkey auth

Runtime flow

After init, all communication uses the public key in gRPC metadata:

sequenceDiagram
    participant Agent as banyan-agent
    participant Engine as banyan-engine

    Agent->>Engine: gRPC call + public key in x-banyan-public-key header
    Engine->>Engine: Look up public key in whitelist
    alt Key found in whitelist
        Engine->>Engine: Process RPC
        Engine-->>Agent: Response
    else Key not found
        Engine-->>Agent: Unauthenticated error
    end

Config files

After initialization, each component stores its keypair:

Engine (/etc/banyan/banyan.yaml):

engine:
  wg_private_key: "base64-encoded-private-key"
  wg_public_key: "base64-encoded-public-key"
  whitelisted_keys_dir: "/etc/banyan/whitelisted-keys"
  grpc_port: "50051"
  store_backend: "etcd"

Agent (/etc/banyan/banyan.yaml):

agent:
  engine_host: "192.168.1.10"
  engine_port: "50051"
  wg_private_key: "base64-encoded-private-key"
  wg_public_key: "base64-encoded-public-key"

CLI (/etc/banyan/banyan.yaml):

cli:
  engine_host: "192.168.1.10"
  engine_port: "50051"
  wg_private_key: "base64-encoded-private-key"
  wg_public_key: "base64-encoded-public-key"

Key management

• Generate: Running init on any component generates a new X25519 keypair.
• Whitelist: Copy the public key (displayed during init) to the engine’s whitelisted keys directory as a .pub file.
• Revoke: Delete the .pub file from the engine’s whitelisted keys directory and restart the engine.
• Rotate: Re-run init on the component to generate a new keypair, then update the .pub file on the engine.

Whitelisting keys

After running init on an agent or CLI, copy the displayed public key to the engine:

# On the agent machine (after banyan-agent init)
cat /etc/banyan/banyan.yaml | grep wg_public_key
# Output: wg_public_key: "abc123..."

# On the engine machine
sudo banyan-engine add-client --name worker-1 --pubkey 'abc123...'

Or copy directly between machines:

# From agent to engine
ssh engine-host "echo '$(grep wg_public_key /etc/banyan/banyan.yaml | awk '{print $2}')' > /etc/banyan/whitelisted-keys/worker-1.pub"

The filename (minus .pub) becomes the agent’s display name in logs.

Non-interactive init

All init commands can be run non-interactively by pre-writing the config file:

# Write config first
cat > /etc/banyan/banyan.yaml <<EOF
agent:
  engine_host: "192.168.1.10"
  engine_port: "50051"
EOF

# Run init (generates keypair, skips prompts since config exists)
sudo banyan-agent init

WireGuard control tunnel

When the engine’s WireGuard public key is provided during agent/CLI init, Banyan creates a wg-control WireGuard interface that encrypts all gRPC traffic at the network layer. No TLS is needed — the tunnel handles encryption transparently.

Control plane tunnel (wg-control):
  Engine (10.200.0.1) <-> Agent (10.200.X.Y)    # encrypted gRPC
  Engine (10.200.0.1) <-> CLI   (10.200.X.Y)    # encrypted gRPC

Data plane tunnel (banyan-wg):
  Agent <-> Agent                                 # encrypted container traffic

How it works:

1. Engine generates a keypair during banyan-engine init and displays its public key.
2. Agents/CLI provide the engine’s public key during their init.
3. On start, each component creates a wg-control interface with a deterministic tunnel IP derived from its public key.
4. gRPC traffic routes through the tunnel automatically.
5. If the tunnel is unavailable (e.g., WireGuard not installed), components fall back to direct TCP with public key metadata auth.

Port: 51821/UDP on the engine (agents/CLI connect to this port).

Config fields:

agent:
  engine_wg_public_key: "engine-public-key-base64"  # enables control tunnel

cli:
  engine_wg_public_key: "engine-public-key-base64"  # enables control tunnel

Security properties

Property	How
No passwords or shared secrets	Each component has a unique keypair. No cluster-wide password.
Keys are standard X25519	Same format as WireGuard. 32 bytes, base64-encoded.
Dual-purpose keypair	Same key for gRPC auth (control plane) and WireGuard tunnels (data plane).
Per-component revocation	Delete a single .pub file to revoke access for one agent/CLI.
No token storage in etcd	Public keys are stored as flat files on the engine. No etcd dependency for auth.
Private keys never leave the machine	Only the public key is copied to the engine.
Control plane encryption	When enabled, all gRPC traffic is encrypted via WireGuard tunnel.

---

mTLS (planned)

Mutual TLS authentication will allow components to authenticate using X.509 client certificates instead of public keys.

sequenceDiagram
    participant CA as Certificate Authority
    participant Engine as banyan-engine
    participant Agent as banyan-agent

    Note over CA,Agent: Setup (one-time)
    CA->>Engine: Issue server cert + key
    CA->>Agent: Issue client cert + key

    Note over Engine,Agent: Runtime
    Agent->>Engine: gRPC + TLS handshake (client cert)
    Engine->>Engine: Verify client cert against CA
    Engine-->>Agent: Authenticated connection

This will be suitable for environments with existing PKI infrastructure or stricter security requirements. See the roadmap for status.

---

OIDC / SSO (planned)

OpenID Connect integration will allow Banyan to delegate authentication to an external identity provider (e.g., Google, Okta, Keycloak).

sequenceDiagram
    participant User
    participant CLI as banyan-cli
    participant IdP as Identity Provider
    participant Engine as banyan-engine

    User->>CLI: banyan-cli init --auth oidc
    CLI->>IdP: Redirect to login
    User->>IdP: Authenticate
    IdP-->>CLI: ID token
    CLI->>Engine: Authenticate with ID token
    Engine->>IdP: Verify token
    Engine-->>CLI: Whitelisted
    CLI->>CLI: Save config

This will be suitable for teams with centralized identity management. See the roadmap for status.
